Elegoo Mars 4 Max
Resin printer with 6K resolution for incredibly precise work
£253.13 £290.00 -13%
(Price shown includes 20% VAT. - Excludes delivery costs)
Features & Advantages
- Large build volume
- 9.1-inch 6K LCD screen
- Tempered glass screen protector
- Sandblasted build plate
- Efficient heat dissipation
Looking for spare parts for this product?
Item no.: ELG-50101010300, Content: 1 pc, EAN: 50.101.010300
Product information & technical details
- Item no.: ELG-50101010300
- Manufacturer No.: 50101010300
- Manufacturers: Elegoo
- Content: 1 pc
- Product types: 3D Printers
- Light source: LCD
- Assembly: Fully assembled
- Printer Display: Touch Display
- Interfaces: USB - Connection
- Building platform : 195.84 x 122.4 x 150 mm
The Elegoo Mars 4 Max is a resin 3D printer with a build volume of 195.84 x 122.4 x 150 mm that lets you realise countless creative projects! The printer uses a COB refraction light source with an anti-aliasing algorithm, through which the anti-aliasing effect is greatly improved. Not only does the print quality turns out higher, but also the details of the printed models are more realistic and their surface appears smoother and finer.
9.1-inch 6K LCD screen
Mars 4 Max is equipped with a 9.1-inch 6K LCD screen. The incredibly high print resolution of 5760 x 3600 pixels (34 um) allows for reduced exposure time to 1.5-3 seconds per layer, which helps to significantly improve print efficiency and print speeds of up to 70 mm/h.
Toughened glass screen protector
To effectively protect the printer's LCD screen, the Mars 4 Max is equipped with a replaceable tempered glass screen protector (9H hardness). The easy-to-clean glass protector prevents screen smudges and scratches, as well as the ingress of resins and other liquids.
Sandblasted build plate
The Mars 4 Max's build plate is sandblasted. Such a build plate ensures strong adhesion to the underside of the model and achieves a much higher success rate when printing.
Reinforced Z-axis for more stable operation
The Z-axis rail has been reinforced in width to effectively minimise vibration for more stable operation and precision.
Double fan cooling system for efficient heat dissipation and cooling
The dual fan cooling system provides more efficient cooling, which also extends the life of the printer in the long run.
Three print modes
The LCD printer is equipped with intelligent Voxeldance Tango slicing software. Three different printing modes are available to users:
- Static mode for printing according to preset parameters,
- Smooth mode, in which the printing speed is dynamically adjusted to various factors (e.g. size of the model section),
- High-speed mode, in which the printing process is completed faster with improved printing efficiency based on the smooth mode.
Open Source GOO
The new open-source GOO was developed by Elegoo and is compatible with a wide range of slicing software.
A wide range of application possibilities
Mars 4 Max can be applied in a variety of fields: R&D, dentistry, education, design, miniature and jewellery making are just some of them.
Mars 4, Mars 4 Ultra and Mars 4 Max in comparison:
|Mars 4||Mars 4 Ultra||Mars 4 Max|
|Device Size||230 x 230 x 440 mm||230 x 230 x 455 mm||250 x 230 x 455 mm|
|Weight||5.2 kg||7 kg||7.5 kg|
|Build Volume||153.36 x 77.76 x 175 mm||153.36 x 77.76 x 165 mm||195.84 x 122.4 x 150 mm|
|Print Speed||30-70 mm/h|
|LCD-Screen+ Resolution||9K 6.7-Inch Monochrome LCD||6K 9.1-Inch Monochrome LCD|
|XY-Resolution||18 µm||34 µm|
|Light Source||COB-Light Source||COB+Fresnel Collimating Light Source||COB-Light Source + Refractive Lense|
|Screen Protector||-||9H Tempered Glass + PFA-Release Film|
|Levelling||Standard (2 Screws)||One-time 4-point levelling||Standard (2 Screws)|
|Build Platform||Laser Engraved Build Platform||Sandblasted Build Platform|
|Printer Display||3.5-Inch Resistive Touchscreen||4-Inch Capacitive Touchscreen||3.5-Inch Touchscreen|
|Data Interfaces||USB||USB, WiFi||USB|
|Plug-in Air Purifier||Yes|
|Slicer||Voxeldance Tango; compatible with CHITUBOX, Lychee|
